Step 1: Setup & Access. Plug your KM003C into the power source and link your device via Type-C. Toggle the top buttons to reach the "Charging Waveform" screen to start tracking live voltage and current data.
Step 2: Monitoring Channels. Hit the center button to switch views. Beyond standard V/A metrics, you can inspect D+/D- and CC1/CC2 pins—essential for troubleshooting protocol handshakes and signal integrity.
Step 3: Sampling Control. The Confirmation button lets you jump between 2sps and 1ksps. Use 1ksps to catch micro-ripples and noise, or drop down to 2sps to monitor a full charging cycle from 0% to 100%.
Step 4: Pro Tips. Always use high-wattage rated cables to ensure data accuracy. Note that 1ksps mode is for live monitoring only—history is disabled at this speed. If you see jagged lines, check your connections or the charger's quality, as this usually indicates high ripple or a loose port.
